General Specs |
| Product Weight (lbs.) | 46 |
| Color | Stainless Steel |
| Element Type | Ribbon Radiant |
| Fuel Type | Electric |
| Depth (in.) | 20.5 |
| Height (in.) | 5.56 |
| Width (in.) | 36.13 |
| Manufacturer Warranty | 1 Year Parts & Labor |
| Appliance Fit Width (in.) | 36 |
| Color Finish Name | Stainless Steel Frame |
| ADA Compliant | No |
| ENERGY STAR Certified | No |
| Number of Elements Burner Cooking Zones | 5 |
| Commercial Use Approved | No |
| Smart Compatible | No |
| Smart Home Wifi | No |
| Number of Elements/Burners | 5 |
| Voltage | 208/240 |
| Frequency | 60 |
| Amp | 40 |
| Cooktop Surface | Glass |
Features |
| Cooktop Burner Type | Smoothtop |
| Control Location | Front Center |
| Control Type | Knob (Infinite switch) |
| Cooktop Control Features | Control Lock Capability; Keep-Warm Setting; Melt Setting; Sync-Burners Capability |
| Dishwasher Safe Knobs | Yes |
| Melt Setting | Yes |
| Indicator Lights | 5 Hot Surface; Red; Surface Element "ON" |
Appearance |
| Frame Color / Material | Stainless Steel |
| Control Knobs | Stainless Steel Appearance |
Weights and Dimensions |
| Cabinet Width | 36 in |
| Cooktop Size | 36 in |
| Cutout Dimensions (Width x Depth) (In.) | 33-7/8 x 19-1/8 |
Power/Ratings |
| Max. Connected Load (kW) at 208V | 7.2 |
| Max. Connected Load (kW) at 240V | 9.6 |
| Max. Current Draw (Amps) at 208V | 34.7 |
| Max. Current Draw (Amps) at 240V | 40.0 |
| Recommended Circuit Breaker (Amps) at 208V | 40 |
| Recommended Circuit Breaker (Amps) at 240V | 40 |
